Waveshare RP2350-Zero Mini Development Board – Dual-Core Dual-Architecture RP2350 MCU Board (Pakistan)
The Waveshare RP2350-Zero is a compact, Pico-style microcontroller development board built around the official Raspberry Pi RP2350 chip. Featuring a unique dual-core, dual-architecture design — dual-core Arm Cortex-M33 plus dual-core Hazard3 RISC-V — this tiny board delivers desktop-class flexibility in a footprint small enough for wearables, embedded electronics, and space-constrained IoT projects. With a USB Type-C connector, 4MB onboard flash, 520KB SRAM, and castellated edge pads for direct SMD soldering, it's built for makers, students, and professional embedded developers across Pakistan who need a reliable, fast, and affordable RP2350 board.
Key Features
- Powerful Dual-Architecture Processor: Dual-core Arm Cortex-M33 + dual-core Hazard3 RISC-V, clockable up to 150MHz — switch architectures in firmware for maximum project flexibility.
- Ultra-Compact "Zero" Form Factor: Ideal for wearables, drones, robotics, and any project where board size matters.
- USB Type-C Connectivity: Modern connector for power, programming, and USB 1.1 host/device data — supports drag-and-drop firmware flashing via USB mass storage (DFU/bootloader mode), no special programmer required.
- Rich I/O for Any Project: 29 multi-function GPIO pins, 2× SPI, 2× UART, 2× I2C, 4× 12-bit ADC, and 16 controllable PWM channels.
- 12× Programmable I/O (PIO) State Machines: Build custom peripherals and protocols entirely in hardware-accelerated software.
- Developer Friendly: Fully compatible with the Raspberry Pi ecosystem — program in C/C++ or MicroPython with full community and SDK support.
- Onboard Extras: WS2812 RGB LED, onboard temperature sensor, accelerated floating-point library, low-power sleep/dormant modes, BOOT and RUN buttons, and debug pins for advanced development.
Full Specifications
| MCU | Raspberry Pi RP2350-Zero (designed in the UK) |
| Architecture | Dual-core Arm Cortex-M33 + Dual-core Hazard3 RISC-V (up to 150MHz) |
| Memory | 520KB SRAM, 4MB onboard NOR Flash |
| Connector | USB Type-C, USB 1.1 host & device support |
| GPIO | 29× multi-function pins (20 via edge pinout, remaining via solder points) |
| Interfaces | 2× SPI, 2× I2C, 2× UART, 4× 12-bit ADC, 16× PWM |
| PIO | 12× Programmable I/O state machines |
| Extras | Onboard temperature sensor, WS2812 RGB LED, accurate on-chip clock/timer |
| Power Regulator | ME6217C33M5G LDO, 800mA max output |
| Programming | Drag-and-drop via USB mass storage; BOOT + RUN buttons for entering download/bootloader mode |
| Mounting | Castellated module — solderable directly onto carrier boards for SMD integration |
| Software Support | C/C++ SDK, MicroPython, full Raspberry Pi Pico ecosystem compatibility |
Who Is This Board For?
The RP2350-Zero is a versatile pick for hobbyists, students, and engineers building embedded systems, IoT sensors, wearable electronics, robotics controllers, custom PIO-based peripherals, and general-purpose USB/bootloader-based firmware development projects. Its small size and castellated pads also make it a strong choice for makers designing their own custom carrier boards or production-ready embedded products.
What's in the Box
- 1 × Waveshare RP2350-Zero Mini Development Board
Frequently Asked Questions
Is the RP2350-Zero compatible with Raspberry Pi Pico code and libraries?
Yes. The board is fully compatible with the official Raspberry Pi Pico SDK and ecosystem, supporting both C/C++ and MicroPython development.
What is the difference between RP2350-Zero and Raspberry Pi Pico?
The RP2350-Zero uses the newer RP2350 chip with a dual-core, dual-architecture design (Cortex-M33 + RISC-V) and a much smaller "Zero" form factor with a USB Type-C connector, compared to the original Pico's single-architecture RP2040 chip and micro-USB port.
Can I buy the Waveshare RP2350-Zero online in Pakistan?
Yes, the Waveshare RP2350-Zero is available for order on Bzar.pk with delivery across Pakistan, including Lahore, Karachi, Islamabad, Faisalabad, and Bahawalpur.
Does it support drag-and-drop firmware flashing?
Yes, the board supports drag-and-drop programming via USB mass storage mode, making firmware updates simple even for beginners.
Why Buy the RP2350-Zero from Bzar.pk?
Bzar.pk brings genuine Waveshare development boards to makers and engineers across Pakistan — Lahore, Karachi, Islamabad, Faisalabad, Multan, and nationwide — with fast local delivery via TCS and Leopard Courier, secure payment options, and support from a marketplace built by people who understand embedded electronics and repair-tech hardware.
